| Max.PV input power(KW) | 9 | 12 | 15 | 18 | 22.5 |
| Max.PV voltage(V) | 1,000 | ||||
| MPPT voltage range(V) | 180~850 | ||||
| Full power MPPT voltage range(V) | 250~850 | 330~850 | 430~850 | 510~850 | 620~850 |
| Min.input voltage/start-up voltage(V) | 125/180 | ||||
| Max.input current per MPPT(A) | 13/13 | ||||
| Max.short-circuit current(A) | 16/16 | 25/25 | |||
| No.of MPPT trackers | 2 | ||||
| No.of strings per MPPT trackers | 1/1 | 1/2 | |||
| Rated PV input voltage(V) | 700 | ||||
| AC Output | |||||
| Nominal output power to grid (kVA) | 6 | 8 | 10 | 12 | 15 |
| Max. apparent power to grid (kVA) | 6.6 | 8.8 | 11 | 13.2 | 16.5 |
| Max. apparent power from grid (kVA) | 13.2 | 17.6 | 22 | 26.4 | 33 |
| Max. apparent current from grid (A) | 19.1 | 25.5 | 31.8 | 38.2 | 47.6 |
| Nominal output current to grid (A) | 8.7 | 11.5 | 14.4 | 17.3 | 21.7 |
| Max.output current to grid (A) | 9.5 | 12.7 | 15.9 | 19.1 | 23.8 |
| Nominal grid voltage (V) | 380/400 ,3W+N+PE | ||||
| Nominal grid frequency (Hz) | 50/60 | ||||
| THDi | < 3% | ||||
| Battery | |||||
| Max.charging /discharging power (kW) | 6.6 | 8.8 | 11 | 13.2 | 16.5 |
| Battery voltage range (V) | 125~600 | ||||
| Battery optimal operating voltage (V) | 150~550 | ||||
| Max.charging /discharging current (A) | 50 | ||||
| Rated.charging /discharging current (A) | 40 | ||||
| Battery type | Lithium /Lead-acid | ||||
| Communication interface | CAN | ||||
| EPS Output | |||||
| Nominal output power (kVA) | 6 | 8 | 10 | 12 | 15 |
| Max. apparent power (kVA) | 6.6 | 8.8 | 11 | 13.2 | 16.5 |
| Nominal output current (A) | 8.7 | 11.5 | 14.4 | 17.3 | 21.7 |
| Max.output current (A) | 9.5 | 12.7 | 15.9 | 19.1 | 23.8 |
| Nominal output voltage (V) | 400 ,3W+N+PE | ||||
| Nominal output frequency (Hz) | 50/60 | ||||
| THDu | < 2% | ||||
| Max.efficiency | 97.9% | 97.9% | 98.2% | 98.2% | 98.5% |
| Europe efficiency | 97.2% | 97.2% | 97.5% | 97.5% | 97.6% |
| MPPT efficiency | ≥ 99.5% | ||||
| Max.battery charge/discharge efficiency | 97.5% | 97.5% | 97.5% | 97.6% | 97.8% |
| General Data | |||||
| Ingress protection | IP65 | ||||
| Operating temperature range (℃) | -25~60 | ||||
| Relative humidity | 0~95% | ||||
| Operating altitude (m) | 4,000 (>2,000 Derating) | ||||
| Dimensions W*H*D (mm) | 566*596*220 | ||||
| Net weight (kg) | 32 | ||||
| Self-consumption at night (W) | < 15 | ||||
| Cooling | Natural | ||||
| Noise emission (dB) | ≤ 35 | ||||
| EMC | IEC/EN 61000-6-1:2019, IEC/EN 61000-6-2:2019, IEC/EN 61000-6-3:2021, IEN/EN 61000-6-4:2019, IEC/EN61000-3-2:2019/A1:2021, EN61000-3-3:2013/A2:2021, IEC/EN61000-3-11:2019, EN 61000-3-12:2021 |
||||
| On-grid | Europe: EN 50549-1:2019/AC:2019, Poland:EN50549-1:2019/Rfg:2016/NC Rfg:2018/PTP/REE:2021, Germany:VDE-AR-N 4105:2018, UK:G99/G98-1:2022, DIN VDE V 0124-100:VDE 0124-100:2020, South Africa: NRS 097-2-1:2017 Edition 2.1, Spain:UNE217001:2020 /UNE217002:2020/NTS V2.1:2021-07, IEC61727:2004/IEC62116:2014/IEC61683:1999, Hungary:EN50549-1:2019/RFG:2016/ Hungary, Italy CEI0-21 |
||||
| Safety standard | IEC/EN62109-1:2010, IEC/EN62109-2:2011 | ||||
| Display and communication | |||||
| HMI | LCD; APP | ||||
| BMS | CAN | ||||
| EMS/Meter | RS485/RS485 | ||||
| Supported communication interface | WIFI / GPRS | ||||
